Grounding ensures your RV’s electrical system has a safe path for fault current. At a campground, the pedestal already provides grounding. With a portable generator, you may need to create a neutral-to-ground bond so your RV’s protective devices work correctly.
Key Summary:
- A campground pedestal supplies the grounding path through the equipment grounding conductor (EGC).
- Portable generators often have a floating neutral, which can trigger an “open ground” error unless bonded.
- A ground rod is usually not required for a portable generator powering a single RV.
- Grounding and bonding are different but equally important for safe fault clearing.
Safety Disclaimer: Working with electricity is dangerous. If you are not experienced, always consult a licensed electrician or qualified RV technician. Follow the manufacturer’s instructions and current electrical codes. Safety should always come first.
What Grounding Means in an RV
Grounding connects the non-current-carrying parts of your RV, like the chassis and appliance housings, to earth ground through the EGC. This provides stray current a low-resistance path back to the source so a breaker or fuse trips immediately.
Bonding is different—it’s the deliberate connection between neutral and ground at the proper location. Without bonding, your protective devices may not clear faults correctly, and without grounding, dangerous voltages can remain on exposed metal parts.
Grounding Your RV at a Campground Pedestal (Step-by-Step)
The campground pedestal already provides the ground through its EGC. Your responsibility is to make sure the pedestal is safe, connect in the correct sequence, and let your surge protector or EMS confirm proper wiring. Here is the step-by-step process to grounding your RV at a campground:
1. Inspect the pedestal
Before you even pull out your RV cord, carefully look at the power pedestal. Check for signs of charring, burnt plastic, rust, loose outlets, or exposed wires. If the pedestal looks damaged, do not plug in. Report the issue to campground staff so they can repair or assign you a new site.
2. Power off first
Locate the breaker switch on the pedestal and flip it to the “OFF” position. This prevents electrical arcing when you connect your RV plug and ensures you are not handling a live outlet.
3. Use a surge protector or EMS
Plug your surge protector or EMS directly into the pedestal outlet before connecting your RV. This device acts as a first line of defense. A quality EMS will detect wiring faults such as open ground, reverse polarity, or even dangerous overvoltage and will stop power before it reaches your RV.
4. Connect your RV cord
Firmly plug your RV’s shore power cord into the surge protector. Make sure the connection is snug and fully inserted. The EGC in your cord ties the RV’s frame and chassis to the pedestal’s ground, creating a safe fault path.
5. Turn on the breaker and check EMS
Flip the pedestal breaker back to “ON.” Watch your EMS display panel. If it shows normal readings, you’re safe to use the power. If it flashes an error code like “E2 open ground” or “E1 reverse polarity,” do not proceed. Notify campground management immediately.
Important: Never use the neutral conductor as a substitute for ground in RV circuits. This is unsafe and violates electrical codes.
Grounding Your RV With a Portable Generator
Portable generators are often shipped with a floating neutral. This design works fine for tools but looks like an “open ground” to an RV EMS. To make your RV’s protective equipment work properly, you may need to bond the neutral and ground at the generator output.
Why “Open Ground” Errors Happen
Modern surge protectors and EMS devices check for a neutral-ground connection before allowing power through. A floating neutral generator makes them display “E2 open ground” and shut down the circuit, even though the generator powers tools normally.
Method 1: Neutral-Ground Bonding Plug (Recommended)
- What it is: A small, inexpensive plug with a jumper wire between neutral and ground that inserts into a spare receptacle on the generator’s control panel.
- How to use it:
- Make sure the generator is turned off.
- Insert the bonding plug into an unused 15-amp or 20-amp outlet.
- Connect your RV shore power cord to the generator.
- Restart the generator and check your EMS. The “open ground” error should clear.
- Why it matters: It creates the neutral-to-ground reference your RV’s safety equipment needs to trip properly in case of a fault.
Method 2: Ground Rod (Rarely Needed for RVs)
- When required: Ground rods are generally unnecessary for one RV powered by a generator. They may be required in multi-RV setups, rallies, or temporary power installations depending on local code.
- Limitations: Simply driving a ground rod into the soil does not guarantee safe fault clearing. Without a bonded neutral-to-ground connection, the RV may still show “open ground” conditions.
When a Ground Rod Is Not Required
If your generator only supplies your RV through cord-and-plug connections, you typically do not need a ground rod. Instead, focus on bonding and making sure your equipment grounding conductor is intact.
A Note on Transfer Switches and “Separately Derived” Systems
If your generator connects through a transfer switch, grounding rules can change:
- Switched neutral transfer switch: The generator becomes a separately derived system and needs a neutral-ground bond at the generator.
- Solid neutral transfer switch: The neutral remains tied to utility service, and bonding should only happen at the main service.
Because setups vary, always have an electrician verify your configuration.
Common Grounding Mistakes to Avoid
- Running a floating-neutral generator without a bonding plug, causing EMS lockouts.
- Ignoring EMS fault codes or bypassing them instead of fixing the root cause.
- Using the neutral as a ground in RV wiring.
- Relying on a ground rod alone without bonding, assuming it provides full protection.
How To Test and Monitor Grounding
Your EMS is the simplest way to test incoming power. If you troubleshoot further, only use a multimeter if you are comfortable and qualified.
- Check EMS codes: E2 = open ground, E1 = reverse polarity, E3 = 240 volts. Stop immediately if any appear.
- Verify generator bonding: If the EMS shows E2 on generator power, add a bonding plug.
- Inspect cords and adapters: A worn or damaged cord can break the ground path.
- Get professional help: If your readings are inconsistent, contact an electrician.
Quick Scenario Guide
| Scenario | What provides the ground | Neutral-ground bond location | Ground rod needed? | First check |
| Campground pedestal | Park’s equipment grounding conductor | Utility service panel | No | EMS must show normal |
| Portable generator | Generator frame + EGC in cord | At generator output (if floating) | No, for single RV use | EMS reading |
| Generator via transfer switch | Depends on switch design | Generator or main service | Depends on code | Pro inspection |
Emerging Change: Ground Monitoring Interrupters (GMI)
The RV industry is moving toward Ground Monitoring Interrupters. Like GFCIs, these devices cut off power if no proper ground is present. Expect newer RVs to include GMI protection, making safe grounding easier and automatic.
Final Words
When you connect at a campground, the pedestal’s grounding system protects you. Just make sure the pedestal is in good condition, use a surge protector or EMS, and trust its readings.
With a generator, the critical step is whether the neutral must be bonded to ground. For most RV owners, a simple bonding plug is all that’s needed. A ground rod is almost never required.
For complex systems that involve transfer switches or hardwiring, rules are different. If you are not certain about your setup, a licensed electrician can confirm the safest configuration for your RV.
Related FAQs
Do I need a ground rod for my RV?
No, not if you’re powering a single RV from a portable generator. Local rules may differ for multi-unit setups.
Why does my EMS show “E2” with a generator?
Because the generator has a floating neutral. Adding a bonding plug typically resolves this.
What’s the difference between grounding and bonding?
Grounding ties equipment to earth. Bonding connects neutral to ground at the correct point so faults clear.
Can I use neutral as a ground?
Never. The neutral conductor cannot substitute for the equipment ground in an RV.
